STKM13A JIS3445 Precision Seamless Steel Tube , 75*3.5MM Carbon Seamless Steel Pipe Cold Drawing

Name: STKM13A JIS3445 Precision Seamless Steel Tube 7535MM Carbon Seamless Steel Pipe Cold Drawing
Brand: Joyruns
Price: 1 USD

Quality STKM13A JIS3445 Precision Seamless Steel Tube , 75*3.5MM Carbon Seamless Steel Pipe Cold Drawing wholesale

Brand Name : Joyruns

Model Number : STKM 13A, 13B

Certification : ISO9001

Place of Origin : Changzhou

MOQ : 2Tons

Payment Terms : L/C, T/T

Supply Ability : 2000Tons/Month

Delivery Time : 20days

Packaging Details : plastic packing, end caps, wooden box packing

OD size : 6mm to 114.3mm

WT : 0.8mm to 30mm

Type : Seamless cold drawning precision tube

Grade : STKM 11, STKM 11A, STKM 12, STKM 13, STKM 13A

Standard : JIS G3445,

Delivery Condition : +N, +NBK,+C,+LC,+BK,+A

Contact Now

JIS3445 STKM13A precision cold drawing seamless steel tube

Suitable for carbon steel pipe used in machinery, automobile, bicycle, apparatus and other mechanical parts.

STKM 13 Chemical Composition (WT%)

ST52

E355

STKM 13

C≤ 0.25

Si≤ 0.35

Mn0.30 - 0.90

P≤ 0.040

S≤ 0.040

Mechanical Properties:

Standard	Steel Grade	Tensile Strength (MPa)	Yield Point (MPa)	Elongation(%)
JIS G3445	STKM 13A	≥375	≥215	≥30
JIS G3445	STKM 13B	≥440	≥305	≥20

Pipe Tolerance Table
Name	Rang(mm)	German Standard(mm)	Corporate Internal Control Standards(mm)	Special High-Precision(mm)
Outer Diameter	4-30	±0.08	±0.05	±0.03
	31-40	±0.15	±0.05	±0.03
	41-50	±0.20	±0.08	±0.03
	51-60	±0.25	±0.08	±0.03
Wall thickness	0.5-7	±10%	±10%,Min±0.05	±10%,Min±0.03
Length	+/-10mm	Automotive industry pipe length can be cut according to customer requirements.

Heat treatment process delivery conditions:
Delivery Condition	Heat Treatment Process
+C	Cold drawn / hard. After the final cold forming no heat treatment.
+LC	Cold drawn/soft. After the final heat treatment-limiting deformation, cold drawn, allowing a degree of cold deformation
+SR	Steel heat treatment is applied after the last cold deformation process, the result of state steel after due process, the residual stress deformation and machining makes a certain degree of difficulty increases.
+A	In the final step of the steel pipe after cold deformation, placed in a controlled atmosphere furnace for annealing.
+N	In the final step of the steel pipe after cold deformation, placed in a controlled atmosphere furnace at a temperature above the phase transition point to continue annealing.

STKM13A JIS3445 Precision Seamless Steel Tube , 75*3.5MM Carbon Seamless Steel Pipe Cold Drawing
